Floor Mounted Jib Crane & Wall Jib Crane for Sale
Wall Traveling Jib Crane
We offer 360& 270& 180 Degree Rotation floor jib crane and wall jib crane and they mount easily to any substantial structural steel building column, at any desired height.
- Duty group: Class C (intermediate)
- Lifting capacity: 0.5-20t
- Valid radius: 4-10m
- Hoisting speed: Single/ double
Applications of Jib Crane from Manufacturer:
- The most common applications for jib cranes are individual workstations, machine tools, welding/fabrication stations, and some small assembly stations.
- They are also often designed and used in simple loading / unloading operations where it is not necessary to spot a load precisely.
- Jib cranes most often handle lighter loads at lower duty cycles than their bridge and gantry crane counterparts.
- If there is a need for precise locating of heavy loads, a large area of hook coverage, or frequent use for heavy loads, the jib crane may not be the best solution.
Jib Crane Specifications:
| Model | BZ0.5 | BZ1 | BZ2 | BZ3 | BZ5 | ||
|---|---|---|---|---|---|---|---|
| Lift capacity | t | 0.5 | 1 | 2 | 3 | 5 | |
| Max Lift height | m | 3 | 3 | 3 | 4 | 4 | |
| Max. horizontal throw | m | 2.6 | 3-4 | 2.9-3.9 | 3.8 | 3.7 | |
| Max. radius of gyration | m | 3.6 | 4-5 | 4-5 | 5 | 5 | |
| Max. overturning moment | t/m | 3 | 6 | 12 | 18 | 27 | |
| angle of revolution | degree | 360 | |||||
| Lift speed | normal | m/min | 8 (4) | ||||
| slow | m/min | 0.8 (0.4) | |||||
| Travel speed | m/min | 20 | |||||
| angle of revolution speed | m/min | 1 | 0.75 | 0.7 | 0.9 | 0.6 | |
Safety Device of Jib Crane:
- Overload protection device
- Top quality long time bearing polyurethane materials buffer
- Crane traveling limit switch
- Voltage lower protection function
- Emergency stop system
- Lifting height limit device
